  • YMW 374619O M5-0.80MM Cut Spiral Flute Mod Bottom 2.5P-3.0P HSSE-V Uncoated
Picture of YMW 374619O M5-0.80MM Cut Spiral Flute Mod Bottom 2.5P-3.0P HSSE-V Uncoated

YMW 374619O M5-0.80MM Cut Spiral Flute Mod Bottom 2.5P-3.0P HSSE-V Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YMW
SKU: YMW374619O
Delivery date: 3-5 days
$13.88
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Vanadium: increases wear resistance of finishing tools. • Cobalt: enables increased hardening temperatures and improves heat resistance. All types of HSS contain significant amounts of carbon, which reacts with the refractory metals to form hard carbides, which increase wear resistance and hot hardness.

Products specifications
Attribute name Attribute value
General Product Information
Material # Material#16, Material#3, Material#21, Material#23, Material#8, Material#15, Material#20
Package Size 1
Additional Key Information 1 Tapping
Application Cut Tapping, Tapping, Mod Bottom Tapping
Performance Rating High Performance
Shipping State California
Sold by Pieces 1
Uncategorized
Made In USA No
Dimensional Specifications
Thread Limit D4
Tool Material Steel
Shank/Pilot Dia 0.1940 4.93MM
Tap Square 0.1500
Tap Style Cut Spiral Flute
Thread Size M5
Dimension Standard ANSI/ANSI
Flute Direction R - Right
Length Type Standard
Cut Rating <40HRC Steel, Aluminum, Brass, Copper, Ductile Iron, Gray Iron, Stainless Steel
Machine Side TAP0.152x0.194
Machine Side Connection Type Tap Collet
Tap Type Mod Bottom
Thread Type Metric
Tap Chamfer 2.5P-3.0P
Thread Pitch 0.80MM
Overall Len 2.3740 60.30MM
Flutes/Inserts 3
Drill Range 0.1642 4.17MM - 0.1724 4.38MM
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat HSSE-V
Industry-Specific Applications
Aerospace Yes
Job Shop Yes
Mold Yes
Agricultural YES
Medical Yes
