Picture of YG-1 T7405208 M3-0.50mm STI Bottoming 1.5P-2.0P HSSE-V3 Uncoated

YG-1 T7405208 M3-0.50mm STI Bottoming 1.5P-2.0P HSSE-V3 Uncoated

Part Number: YG-T7405208
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$16.36
SKU: 1165915

Description

YG-1 T7405208 M3x0.50MM STI Bottoming 1.5P-2.0P HSSE-V3 Uncoated D2 STI-M Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Tapping
Coolant Thru Non Coolant
Type Of Tool Tap
Length Type STANDARD
Thread Type STI-M
Tap Style STI
Tap Type Bottoming
Tap Chamfer 1.5P-2.0P
Dimensions & Sizing
Overall Length 2.0000 50.80MM
Shank/Pilot Dia 0.1410 3.58MM
Flutes/Inserts 3
Thread Pitch 0.50MM
Thread Size M3
Tap Drill Range 0.1240 3.15MM
Tap Square 0.1100
Performance & Capacity
Cut Rating Aluminum, Stainless Steel, <30HRC Steel, Ductile Iron, Gray Iron
Performance Rating General Performance
Tolerances & Accuracy
Thread Limit D2
Materials & Finish
Tool Material Steel
Cutting Edge Mat HSSE-V3
Standards & Identification
Dimension Standard ANSI/ANSI
