XACTFORM 78132 Carbide Thread Mill 1-3/4" 5.00TPI Int / Ext 0.745 Dia 4.100 OAL 6 Flute

Need Assistance or Service? Please call 262-251-4020

Manufacturer: XACTFORM
SKU: XAC78132
Delivery date: 3-5 days
$744.70
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Coating TiAlN
Package Size 1
Additional Key Information 1 Mill Thread
Performance Rating High Performance
Application Thread Milling
Sold by Pieces 1
Shipping State Florida
Grade K27C
Uncategorized
Made In USA No
Dimensional Specifications
Thread Size 1-3/4"
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Overall Len 4.1000 104.14MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Thread Pitch 5.00TPI
Cut Rating <40HRC, Stainless, Iron, High Temp
Length Of Cut 1.4000 35.56MM
Machine Side CYLINDRICAL0.7500
Machine Side Connection Type Cylindrical
Cutter Dia 0.7450 18.92MM
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Carbide
Inter/Extern Int / Ext
Industry-Specific Applications
Aerospace Yes
Automotive Yes
Job Shop Yes
Medical Yes
Energy Yes
