XACTFORM 70143 Carbide Thread Mill #10 32.00TPI Int / Ext 0.146 Dia 1.970 OAL 3 Flute

Need Assistance or Service? Please call 262-251-4020

Manufacturer: XACTFORM
SKU: XAC70143
Delivery date: 3-5 days
$152.90
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Coating TiN
Additional Key Information 1 Mill Thread
Performance Rating High Performance
Package Size 1
Application Thread Milling
Sold by Pieces 1
Grade K20
Shipping State Florida
Uncategorized
Made In USA No
Dimensional Specifications
Thread Pitch 32.00TPI
Tool Material Carbide
Machine Side Connection Type Cylindrical
Machine Side CYLINDRICAL0.1875
Shank/Pilot Dia 0.1870 4.75MM
Cut Rating <40HRC, Stainless, Iron, High Temp
Length Of Cut 0.4060 10.31MM
Thread Size No.10
Machine Side Connection Size 0.1875 4.75MM
Cutter Dia 0.1460 3.71MM
Overall Len 1.9700 50.04MM
Cutting & Machining Properties
Inter/Extern Int / Ext
Coolant Thru No
Cutting Edge Mat Carbide
Industry-Specific Applications
Medical Yes
Energy Yes
Aerospace Yes
Automotive Yes
Job Shop Yes
