XACTFORM 40103 Carbide Thread Mill #2 56.00TPI Internal 0.065 Dia 1.500 OAL 3 Flute

Need Assistance or Service? Please call 262-251-4020

Manufacturer: XACTFORM
SKU: XAC40103
Delivery date: 3-5 days
$173.80
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Sold by Pieces 1
Grade K20C
Package Size 1
Performance Rating High Performance
Additional Key Information 1 Mill Thread
Shipping State Florida
Application Thread Milling
Coating TiN
Uncategorized
Made In USA No
Dimensional Specifications
Machine Side CYLINDRICAL0.1250
Neck Length 0.1730 4.39MM
Cut Rating <40HRC, Stainless, Iron, High Temp
Thread Size No.2
Cutter Dia 0.0650 1.65MM
Overall Len 1.5000 38.10MM
Flutes/Inserts 3
Tool Material Carbide
Machine Side Connection Type Cylindrical
Machine Side Connection Size 0.1250 3.18MM
Shank/Pilot Dia 0.1250 3.18MM - 1/8
Thread Pitch 56.00TPI
Cutting & Machining Properties
Cutting Edge Mat Carbide
Inter/Extern Internal
Coolant Thru No
Industry-Specific Applications
Energy Yes
Aerospace Yes
Automotive Yes
Job Shop Yes
Medical Yes
