Widin WXR50401202 Dia 1.20mm SH 0.2362 LOC 0.1181 OAL 1.968 End Mill Variable Helix Carbide AlTiN Single End Corner Radius0.0079 0.20mm WINNER

Part Number: WIDWXR50401202
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$31.34
SKU: 1225520

Description

WIDIN Variable Helix End Mill Carbide AlTiN Corner Radius 0.0079 0.20MM 4 Flute Single End WINNER
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Solid End Mill
Coolant Thru Non Coolant
Length Type STANDARD
End Of Tool Shape CORNER RADIUS
Cutter Style Carbide Bull Nose Finisher
Single/Double End Single End
Inch/Metric Metric
Center Cutting Center Cutting
Dimensions & Sizing
Overall Length 1.9685 50.00MM
Length Of Cut 0.1181 3.00MM
Flutes/Inserts 4
Shank/Pilot Dia 0.2362 6.00MM
Tool Dia 0.0472 1.20MM
Geometry & Angles
Helix Angle Variable
Corner Radius 0.0079 0.20MM
Performance & Capacity
Performance Rating High Performance
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Materials & Finish
Cutting Edge Mat Carbide
Coating ALTIN
Tool Material Carbide
