Picture of Widin PF50515081 15.081mm Dia 140° Point 2 Flute 5XD Drill Carbide Non Coolant

Widin PF50515081 15.081mm Dia 140° Point 2 Flute 5XD Drill Carbide Non Coolant

Part Number: WIDPF50515081
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$307.72
SKU: 1144861

Description

WIDIN PF50515081 Carbide Drill 15.081MM DIA 140° Point 2 Flute 5XD Drill Solid TiAlN + HH
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Carbide Drill
Coolant Thru Non Coolant
Type Of Tool Drill
Dimensions & Sizing
Overall Length 5.9843 152.00MM
Flute Length 3.5430 89.99MM
Dia Deep 5.0x Dia
Flutes/Inserts 2
Shank/Pilot Dia 0.6299 16.00MM
Tool Dia 0.5938 15.08MM - 19/32
Geometry & Angles
Included Angle 140°
Performance & Capacity
Cut Dia Min 0.5938 15.08MM - 19/32
Cut Rating <60HRC Steel, Ductile Iron, Grey Iron, Stainless Steel
Materials & Finish
Cutting Edge Mat Carbide
Coating TiAlN + HH
Tool Material Carbide
