Picture of Widia/Kennametal M690D200Z05S075SD12 90.0° Milling Cutter 2.000 Cutter Diameter Face Mill 0.750

Widia/Kennametal M690D200Z05S075SD12 90.0° Milling Cutter 2.000 Cutter Diameter Face Mill 0.750

Part Number: WID2646785 ISO: M690D200Z05S075SD12 ANSI:M690D200Z05S075SD12
Tool Cross-Reference
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1017895
Vendor: Sussex Tool and Supply
$592.39

Description

WIDIA 2646785 90.0°, End Mill SHELL0.7500 Positive 2.0000 50.80MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State PENNSYLVANIA
Made In USA NO
Cutter Type End Mill
Coolant Thru Thru Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style SD
Insert Shape/Cutter Pocket Shape Other
Insert Type Positive
Hand Right Hand
Dimensions & Sizing
Overall Length 1.5000 38.10MM
Flutes/Inserts 5
Tool Dia 2.0000 50.80MM
Length Of Cut 0.4000 10.16MM
Insert Size Ic 12
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Max RPM 22400
Materials & Finish
Tool Material Steel
