Picture of Widia/Kennametal CCPI3126225R Carbide 45.0° Insert Boring Bar 0.312

Widia/Kennametal CCPI3126225R Carbide 45.0° Insert Boring Bar 0.312

Part Number: WID2831739 ISO: CCPI3126225R ANSI:CCPI3126225R
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1076108
Vendor: Sussex Tool and Supply
$385.11

Description

WIDIA 2831739 45.0 ° Boring Bar Dia0.3125 Positive Carbide
Products specifications
Attribute name Attribute value
General Information
Shipping State PENNSYLVANIA
Made In USA NO
Cutter Type Boring Bar
Coolant Thru Thru Coolant
Type Of Tool Boring Bar
Insert/Tool TOOL
Cut Type General Purpose
Insert Style GP
Insert Shape/Cutter Pocket Shape 45.0°
Insert Type Positive
Hand Right Hand
Inter/Extern Internal
Dimensions & Sizing
Overall Length 6.0000 152.40MM
Shank/Pilot Dia 0.3125 7.93MM - 5/16
Flutes/Inserts 1
Insert Size Ic 05 "1.2"
Geometry & Angles
Lead Angle 95°
Lead Angle & Clearance Angle Combined 95° Lead Angle
Performance & Capacity
Min Bore 0.4480
Materials & Finish
Tool Material Carbide
