Picture of Widia/Kennametal 5402213 M18-1.50mm Cut Spiral Flute Mod Bottom 2.5P-3.0P HSSE Uncoated

Widia/Kennametal 5402213 M18-1.50mm Cut Spiral Flute Mod Bottom 2.5P-3.0P HSSE Uncoated

Part Number: WID5402213

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: 1170952
Vendor: Sussex Tool and Supply
$72.53
WIDIA 5402213 M18x1.50MM Cut Spiral Flute Mod Bottom 2.5P-3.0P HSSE Uncoated 6H Metric Steel
Products specifications
Attribute name Attribute value
Shipping State Ohio
Made In USA NO
Cutter Type Tapping
Tool Material Steel
Cutting Edge Mat HSSE
Machine Side Connection Type Tap Collet
Cut Rating Aluminum, Brass, Stainless Steel, <40HRC Steel, Copper
Overall Length 4.3300 109.98MM
Coolant Thru Non Coolant
Shank/Pilot Dia 0.5512 14.00MM
Flutes/Inserts 4
Type Of Tool Tap
Length Type STANDARD
Performance Rating High Performance
Thread Pitch 1.50MM
Thread Type METRIC
Flute Direction RIGHT
Thread Size M18
Thread Limit 6H
Tap Style Cut Spiral Flute
Tap Type Mod Bottom
Dimension Standard DIN/DIN
Tap Drill Range 0.6472 16.44MM - 0.6626 16.83MM
Tap Square 0.4330
Tap Chamfer 2.5P-3.0P
