TUNGALOY VSSD16L090S10-C DIA 15.20MM SH 0.6299 LOC 1.5748 OAL3.54Replacable Head Acc. Straight Neck/Cylicrical Shank Carbide Single End TUNG MEISTER

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6859175
Delivery date: 3-5 days
$467.65
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Shipping State Illinois
Application Copy Milling, Feed Milling, Face Milling, Groove Milling, Profile Milling, Circle Segment, Slot Milling, Side Milling, Dovetail Milling
Performance Rating High Performance
Additional Key Information 1 Screw On Head Acc.
Additional Key Information 3 Straight Neck/Cylicrical Shank
Package Size 1
Sold by Pieces 1
Additional Key Information 2 Replacable Head Shanks
Uncategorized
Made In USA No
Dimensional Specifications
Length Type Standard
Dimension Description 0.598 x 0.630 x 1.575 x 3.543
Machine Side Connection Type Cylindrical
Overall Len 3.5433 90.00MM
Single/Double End Single End
Cutter Style Screw On Tungaloy Shank
Machine Side CYLINDRICAL0.6299
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Length Of Cut 1.5748 40.00MM
Inch/Metric Metric
Cutter Dia 0.5984 15.20MM
Tool Material Steel
Cutting & Machining Properties
Center Cutting No
Coolant Thru No
Cutting Edge Mat Carbide
Part Side TUNGM10
Electrical & Power Specifications
Output Type Screw On Head
Output TUNGM10
Industry-Specific Applications
Automotive Yes
Agricultural YES
Medical Yes
Energy Yes
Aerospace Yes
Job Shop Yes
Mold Yes
