Picture of Tungaloy TID190F25-1.5 19mm DrillMeister Indexable Head Drill with Flanged Shank

Tungaloy TID190F25-1.5 19mm DrillMeister Indexable Head Drill with Flanged Shank

Part Number: TUN6862677 ISO: TID190F25-1.5

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: 1131151
Vendor: Sussex Tool and Supply
$387.62
TUNGALOY TUN6862677 Indexable Drill Dia0.9843 0.7480 19.00MM Cutter Dia Flute Length 1.2990 32.99MM Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Cutter Type Drill
Tool Material Steel
Machine Side Connection Type Boring Bar, Weldon
Mach Side Connection Size 0.9843 25.00MM
Overall Length 4.5079 114.50MM
Coolant Thru Thru Coolant
Shank/Pilot Dia 0.9843 25.00MM
Flutes/Inserts 2
Tool Dia 0.7480 19.00MM
Type Of Tool Drill
Included Angle 136°
Flute Length 1.2990 32.99MM
Cut Dia Min 0.7480 19.00MM
Dia Deep 1.5.0x Dia
Drill Type Indexable Drill
Type Indexable Drill Single Insert
Cut Dia Max 0.7835 19.90MM
Multi Spindle Yes
