Picture of Tungaloy TID180F25-5 18mm DrillMeister Indexable Head Drill with Flanged Shank

Tungaloy TID180F25-5 18mm DrillMeister Indexable Head Drill with Flanged Shank

Part Number: TUN6706794 ISO: TID180F25-5

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: 1131019
Vendor: Sussex Tool and Supply
$472.79
TUNGALOY TUN6706794 Indexable Drill Dia0.9843 0.7087 18.00MM Cutter Dia Flute Length 3.6610 92.99MM Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Cutter Type Drill
Tool Material Steel
Machine Side Connection Type Boring Bar, Weldon
Mach Side Connection Size 0.9843 25.00MM
Overall Length 6.8701 174.50MM
Coolant Thru Thru Coolant
Shank/Pilot Dia 0.9843 25.00MM
Flutes/Inserts 2
Tool Dia 0.7087 18.00MM
Type Of Tool Drill
Included Angle 136°
Flute Length 3.6610 92.99MM
Cut Dia Min 0.7087 18.00MM
Dia Deep 5.0x Dia
Drill Type Indexable Drill
Type Indexable Drill Single Insert
Cut Dia Max 0.7441 18.90MM
Multi Spindle Yes
