Picture of Tungaloy TID080F12-5 8mm DrillMeister Indexable Head Drill with Flanged Shank

Tungaloy TID080F12-5 8mm DrillMeister Indexable Head Drill with Flanged Shank

Part Number: TUN6751955 ISO: TID080F12-5

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: 1131117
Vendor: Sussex Tool and Supply
$308.97
TUNGALOY TUN6751955 Indexable Drill Dia0.4724 0.3150 8.00MM Cutter Dia Flute Length 1.6540 42.01MM Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Cutter Type Drill
Tool Material Steel
Machine Side Connection Type Boring Bar, Weldon
Mach Side Connection Size 0.4724 12.00MM
Overall Length 3.9528 100.40MM
Coolant Thru Thru Coolant
Shank/Pilot Dia 0.4724 12.00MM
Flutes/Inserts 2
Tool Dia 0.3150 8.00MM
Type Of Tool Drill
Included Angle 136°
Flute Length 1.6540 42.01MM
Cut Dia Min 0.3150 8.00MM
Dia Deep 5.0x Dia
Drill Type Indexable Drill
Type Indexable Drill Single Insert
Cut Dia Max 0.3307 8.40MM
Multi Spindle Yes
