Picture of Tungaloy TID080F12-1.5 8mm DrillMeister Indexable Head Drill with Flanged Shank

Tungaloy TID080F12-1.5 8mm DrillMeister Indexable Head Drill with Flanged Shank

Part Number: TUN6751939 ISO: TID080F12-1.5
Tool Cross-Reference
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1131103
Vendor: Sussex Tool and Supply
$249.65

Description

TUNGALOY TUN6751939 Indexable Drill Dia0.4724 0.3150 8.00MM Cutter Dia Flute Length 0.5510 14.00MM Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Drill
Coolant Thru Thru Coolant
Type Of Tool Drill
Drill Type Indexable Drill
Type Indexable Drill Single Insert
Multi Spindle Yes
Dimensions & Sizing
Overall Length 2.8504 72.40MM
Shank/Pilot Dia 0.4724 12.00MM
Flutes/Inserts 2
Tool Dia 0.3150 8.00MM
Flute Length 0.5510 14.00MM
Dia Deep 1.5.0x Dia
Geometry & Angles
Included Angle 136°
Performance & Capacity
Cut Dia Min 0.3150 8.00MM
Cut Dia Max 0.3504 8.90MM
Materials & Finish
Tool Material Steel
