Picture of TUNGALOY PWLNL2525M08-CHP Stick Tool Trigon Insert Neg,L style, 95deg Approach , Steel Square 0.984 Shank

TUNGALOY PWLNL2525M08-CHP Stick Tool Trigon Insert Neg,L style, 95deg Approach , Steel Square 0.984 Shank

ANSI: PWLNL2525M08-CHP

ISO: PWLNL2525M08-CHP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6755221
Delivery date: 3-5 days
$308.50
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Important Notes

Neg,L style, 95deg Approach

Details

Lever lock type toolholder with 95deg approach angle, for negative 80deg trigon inserts, with channels for high pressure coolant

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Shipping State Illinois
Application Ext.Turning
Package Size 1
Insert Type Negative
Additional Key Information 1 Stick Tool
Additional Key Information 2 Trigon
Sold by Pieces 1
Insert/Tool Tool
Uncategorized
Made In USA No
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.9843 25.00MM
Overall Len 5.9055 150.00MM
Shank/Pilot Dia 0.9843 25.00MM
Lead Angle 95°
Machine Side STICK TOOL0.9843
Insert Size Ic 12 "43"
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Trigon
Hand R/L Left
Inter/Extern External
Insert Style WN
