Picture of Tungaloy PVQNL163-CHP Stick Tool 35.0° Insert Neg,Q/H style, 45deg Approach , Steel Square 1.000 Shank

Tungaloy PVQNL163-CHP Stick Tool 35.0° Insert Neg,Q/H style, 45deg Approach , Steel Square 1.000 Shank

Part Number: TUN6755260 ISO: PVQNL163-CHP ANSI:PVQNL163-CHP
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$511.70
SKU: 1072866

Description

TUNGALOY 6755260 35.0 ° Stick Tool1.0000 Negative Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Stick Tool
Type Of Tool Stick Tool
Insert/Tool TOOL
Cut Type General Purpose
Insert Style VN
Insert Shape/Cutter Pocket Shape 35.0°
Insert Type Negative
Hand Left Hand
Inter/Extern External
Clamp Screw 6831778
Seat/Nest 6937545
Dimensions & Sizing
Overall Length 6.0000 152.40MM
Shank/Pilot Dia 1.0000 25.40MM
Insert Size Ic 16 "33"
Geometry & Angles
Lead Angle 117.5°
Lead Angle & Clearance Angle Combined 117.5° Lead Angle 25.0° Clearance Angle
Clearance Angle 25.0°
Materials & Finish
Tool Material Steel
Compatibility & Fit
Insert Fits 35.0°
