  • TUNGALOY PTGNL163-CHP Stick Tool Triangle Insert Neg,G style, 91deg Approach , Steel Square 1.000 Shank
Picture of TUNGALOY PTGNL163-CHP Stick Tool Triangle Insert Neg,G style, 91deg Approach , Steel Square 1.000 Shank

TUNGALOY PTGNL163-CHP Stick Tool Triangle Insert Neg,G style, 91deg Approach , Steel Square 1.000 Shank

ANSI: PTGNL163-CHP

ISO: PTGNL163-CHP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6755244
Delivery date: 3-5 days
$308.50
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Important Notes

Neg,G style, 91deg Approach

Details

Lever lock type toolholder with 91deg approach angle, for negative triangle inserts TN**33*, with channels for high pressure coolant

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Sold by Pieces 1
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Insert Application General Purpose
Insert Type Negative
Additional Key Information 1 Stick Tool
Additional Key Information 2 Triangle
Uncategorized
Made In USA No
Dimensional Specifications
Insert Size Ic 16 "33"
Machine Side STICK TOOL1.0000
Tool Material Steel
Machine Side Connection Type Stick Tool
Lead Angle 91°
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Overall Len 6.0000 152.40MM
Cutting & Machining Properties
Insert Style TN
Hand R/L Left
Inter/Extern External
Insert Shape/Cutter Pocket Shape Triangle
