Picture of TUNGALOY PDJNL2525 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.984 Shank

TUNGALOY PDJNL2525 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.984 Shank

ANSI: PDJNL2525

ISO: PDJNL2525

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805625
Delivery date: 3-5 days
$96.00
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Important Notes

Neg,J style, 93deg Approach

Details

Lever lock type toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Shipping State Illinois
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Additional Key Information 2 55.0°
Sold by Pieces 1
Additional Key Information 1 Stick Tool
Uncategorized
Made In USA No
Dimensional Specifications
Clearance Angle 27.0°
Machine Side STICK TOOL0.9843
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.9843 25.00MM
Insert Size Ic 12 "43"
Lead Angle 93°
Overall Len 5.9055 150.00MM
Tool Material Steel
Shank/Pilot Dia 0.9843 25.00MM
Cutting & Machining Properties
Inter/Extern External
Hand R/L Left
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
