Picture of TUNGALOY PDJNL2020 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank

TUNGALOY PDJNL2020 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank

ANSI: PDJNL2020

ISO: PDJNL2020

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805622
Delivery date: 3-5 days
$85.30
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Important Notes

Neg,J style, 93deg Approach

Details

Lever lock type toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Additional Key Information 2 55.0°
Sold by Pieces 1
Insert Application General Purpose
Insert Type Negative
Shipping State Illinois
Additional Key Information 1 Stick Tool
Application Ext.Turning
Package Size 1
Uncategorized
Made In USA No
Dimensional Specifications
Overall Len 4.9213 125.00MM
Insert Size Ic 12 "43"
Machine Side Connection Size 0.7874 20.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Clearance Angle 27.0°
Shank/Pilot Dia 0.7874 20.00MM
Lead Angle 93°
Machine Side STICK TOOL0.7874
Cutting & Machining Properties
Insert Style DN
Insert Shape/Cutter Pocket Shape 55.0°
Inter/Extern External
Hand R/L Left
