  • TUNGALOY JSDNCN082 Swiss Stick Tool 55.0° Insert Posi,N style, 62.5deg Approach , Steel Square 0.500 Shank
Picture of TUNGALOY JSDNCN082 Swiss Stick Tool 55.0° Insert Posi,N style, 62.5deg Approach , Steel Square 0.500 Shank

TUNGALOY JSDNCN082 Swiss Stick Tool 55.0° Insert Posi,N style, 62.5deg Approach , Steel Square 0.500 Shank

ANSI: JSDNCN082

ISO: JSDNCN082

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6708776
Delivery date: 3-5 days
$96.50
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Important Notes

Posi,N style, 62.5deg Approach

Details

Screw-on clamp toolholder with 62.5deg approach angle, for positive 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Additional Key Information 1 Stick Tool
Application Swiss, Ext.Turning
Insert/Tool Tool
Additional Key Information 3 Swiss
Shipping State Illinois
Additional Key Information 2 55.0°
Insert Type Positive
Sold by Pieces 1
Package Size 1
Uncategorized
Made In USA No
Dimensional Specifications
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Tool Material Steel
Machine Side Connection Type Stick Tool
Insert Size Ic 07 "21"
Machine Side Connection Size 0.5000 12.70MM
Machine Side STICK TOOL0.5000
Clearance Angle 60.0°
Overall Len 5.0000 127.00MM
Lead Angle 62.5°
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DC
Hand R/L Neutral
Inter/Extern External
