  • TUNGALOY C3ADJNL22050-1104N Quick Change Stick Tool 55.0° Insert EcoTurn Toolholders , ISO 26623 1 (TungCap) , Neg,J style, 93deg Approach , Steel PSC "Capt0 Type" 1.181 Shank
Picture of TUNGALOY C3ADJNL22050-1104N Quick Change Stick Tool 55.0° Insert EcoTurn Toolholders , ISO 26623 1 (TungCap) , Neg,J style, 93deg Approach , Steel PSC "Capt0 Type" 1.181 Shank

TUNGALOY C3ADJNL22050-1104N Quick Change Stick Tool 55.0° Insert EcoTurn Toolholders , ISO 26623 1 (TungCap) , Neg,J style, 93deg Approach , Steel PSC "Capt0 Type" 1.181 Shank

ANSI: C3ADJNL22050-1104N

ISO: C3ADJNL22050-1104N

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6770599
Delivery date: 3-5 days
$316.75
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Important Notes

EcoTurn Toolholders ISO 26623 1 (TungCap) Neg,J style, 93deg Approach

Details

TungCap Double-clamp toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Additional Key Information 4 PSC 3 "Capt0 Type"
Insert Application General Purpose
Insert Type Negative
Shipping State Illinois
Sold by Pieces 1
Additional Key Information 3 Quick Change
Additional Key Information 1 Stick Tool
Insert/Tool Tool
Additional Key Information 2 55.0°
Application Ext.Turning
Package Size 1
Uncategorized
Made In USA No
Dimensional Specifications
Machine Side PSC "Capt0 Type"3
Tool Material Steel
Insert Size Ic 11 "33"
Machine Side Connection Type PSC "Capt0 Type"
Shank/Pilot Dia 1.1811 30.00MM
Clearance Angle 30.0°
Overall Len 1.9690 50.01MM
Min Bore 4.8000
Machine Side Connection Size 1.1810 30.00MM
Lead Angle 93°
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Hand R/L Left
