  • TUNGALOY ADJNL2525X-15-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.984 Shank
Picture of TUNGALOY ADJNL2525X-15-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.984 Shank

TUNGALOY ADJNL2525X-15-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.984 Shank

ANSI: ADJNL2525X-15-CHP-MC

ISO: ADJNL2525X-15-CHP-MC

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN3314761
Delivery date: 3-5 days
$308.50
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Important Notes

Neg,J style, 93deg Approach

Details

Double-clamp toolholders with 93deg approach angle for negative 55deg rhombic insert with high pressure coolant channels. High-pressure coolant capability with tube and direct connection.

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Additional Key Information 2 55.0°
Application Ext.Turning
Package Size 1
Sold by Pieces 1
Insert Application General Purpose
Insert Type Negative
Additional Key Information 1 Stick Tool
Insert/Tool Tool
Shipping State Illinois
Uncategorized
Made In USA No
Dimensional Specifications
Shank/Pilot Dia 0.9843 25.00MM
Lead Angle 93°
Clearance Angle 27.0°
Machine Side STICK TOOL0.9843
Insert Size Ic 12 "43"
Overall Len 4.9213 125.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.9843 25.00MM
Cutting & Machining Properties
Insert Style DN
Inter/Extern External
Hand R/L Left
Insert Shape/Cutter Pocket Shape 55.0°
