THREAD MILL USA TM11BSPT Carbide 1" x 11.00TPI BSPT 0.620 Cut Dia Cylindrical 0.6250 4.000 OAL TIALN

ISO: TM11BSPT

Need Assistance or Service? Please call 262-251-4020

Manufacturer: THREAD MILL USA
SKU: THRTM11BSPT
Delivery date: 3-5 days
$301.50
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Thread Milling
Material # Material#16, Material#8, Material#10, Material#20, Material#5, Material#15
Coating TiAlN
Shipping State Georgia
Sold by Pieces 1
Additional Key Information 1 Mill Thread
Package Size 1
Uncategorized
Made In USA Yes
Dimensional Specifications
Thread Size 1"
Cutter Style Carbide Thread Mill
Thread Pitch 11.00TPI
Machine Side CYLINDRICAL0.6250
Length Of Cut 1.5460 39.27MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Cutter Dia 0.6200 15.75MM
Overall Len 4.0000 101.60MM
Cut Rating <53Hrc Steel,Aluminum,Ductile Iron,Gray Iron,High Temp,Stainless Steel
Tool Material Carbide
Machine Side Connection Type Cylindrical
Helix Angle 28°
Thread Type BSPT
Machine Side Connection Size 0.6250 15.88MM
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
Industry-Specific Applications
Aerospace Yes
Automotive Yes
Job Shop Yes
Mold Yes
Medical Yes
Agricultural YES
Energy Yes
