Picture of Techniks 23030F CAT50 Collet Chuck G100 3.0000 Gauge Length

Techniks 23030F CAT50 Collet Chuck G100 3.0000 Gauge Length

Part Number: TEC23030F ISO: 23030F
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1419974
Vendor: Sussex Tool and Supply
$213.41

Description

Techniks Coolflex Collet Chuck Offer Coolant Either Through The Spindle Or Flange (Din B). Remove Stop Screws For Din B. Balanced To 25,000 Rpm At G2.5 With T.I.R. Of 0.0001". Techniks Certified For Accuracy And Balance And Comes With A Lab Report. Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Coolant Thru Thru Coolant
Type Of Tool Collet Chuck
Output Type TG
CNC Type Tool Collet Chuck
Coolant Type Through Spindle
Flange Coolant DIN A/B
Dimensions & Sizing
Overall Length 7.0100 178.05MM
Gauge Length 3.0000
Nose Dia/Nut Dia 2.362
Performance & Capacity
Output 100
Max RPM 25000
Balanced To 000 RPM at G2.5, 25
Materials & Finish
Tool Material Steel
Compatibility & Fit
CNC Connection CAT50
