Picture of Techniks 23014F CAT40 Collet Chuck G100 3.0000 Gauge Length

Techniks 23014F CAT40 Collet Chuck G100 3.0000 Gauge Length

Part Number: TEC23014F ISO: 23014F

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TECHNIKS
SKU: 1419968
Vendor: Sussex Tool and Supply
$199.00
Techniks Coolflex Collet Chuck Offer Coolant Either Through The Spindle Or Flange (Din B). Remove Stop Screws For Din B. Balanced To 25,000 Rpm At G2.5 With T.I.R. Of 0.0001". Techniks Certified For Accuracy And Balance And Comes With A Lab Report. Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Tool Material Steel
Machine Side Connection Type CAT
Mach Side Connection Size 40
Overall Length 5.6800 144.27MM
Coolant Thru Thru Coolant
Type Of Tool Collet Chuck
Insert/Tool TOOL
Part Side TG100
Output Type TG
Output 100
CNC Type Tool Collet Chuck
CNC Conection CAT40
CNC Out Put TG100
Coolant Type Through Spindle
Gauge Length 3.0000
Max RPM 25000
Nose Dia/Nut Dia 2.362
Balanced To 000 RPM at G2.5, 25
Flange Coolant DIN A/B
