Picture of Techniks 22921-5F CAT40 End Mill 0.7500 19.05 - 3/4 5.0000 Gauge Length

Techniks 22921-5F CAT40 End Mill 0.7500 19.05 - 3/4 5.0000 Gauge Length

Part Number: TEC22921-5F ISO: 22921-5F

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TECHNIKS
SKU: 1419813
Vendor: Sussex Tool and Supply
$252.00
Techniks Techniks Coolflex End Mill Holders Offer Coolant Capability Either Through Spindle Or The Flange(Din B). Techniks End Mills Offer An Industry Leading H5 Bore Tolerance To Increase Tool Life And Are Individually Tested In A Lab To Ensure Quality. Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Tool Material Steel
Machine Side Connection Type CAT
Mach Side Connection Size 40
Overall Length 7.7000 195.58MM
Coolant Thru Thru Coolant
Tool Dia 2.5000 63.50MM - 2-1/2
Type Of Tool End Mill Holder
Insert/Tool TOOL
Part Side WELDON0.7500
Output Type Weldon
Output 0.7500 19.05 - 3/4
CNC Type Tool End Mill
CNC Conection CAT40
CNC Out Put WELDON0.7500
Gauge Length 5.0000
Max RPM 15000
Nose Dia/Nut Dia 1.750
Balanced To 000 RPM at G6.3, 15
Flange Coolant DIN A/B
