Picture of Techniks 22721F CAT50 Shell Mill 0.7500 19.05 - 3/4 1.5000 Gauge Length

Techniks 22721F CAT50 Shell Mill 0.7500 19.05 - 3/4 1.5000 Gauge Length

Part Number: TEC22721F ISO: 22721F
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$176.21
SKU: 1419699

Description

Techniks Coolflex Collet Chuck Offer Coolant Either Through The Spindle Or Flange (Din B). Remove Stop Screws For Din B. Techniks Face Mill Arbors Offerr H6 Arbor Tolerance For Less Chatter And Better Tool Life. Each Arbor Is Lab Certified For Dimensional Accuracy. The Taper Is Ground To At3 Tolerance For Maximum Spindle Contact. Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Coolant Thru Thru Coolant
Type Of Tool Shell Mill Arbor
Output Type SHELL MILL
CNC Type Tool Shell Mill
Coolant Type Spindle/DIN-B
Flange Coolant DIN A/B
Dimensions & Sizing
Overall Length 6.1900 157.23MM
Tool Dia 2.7500 69.85MM - 2-3/4
Gauge Length 1.5000
Performance & Capacity
Output 0.7500 19.05 - 3/4
Materials & Finish
Tool Material Steel
Compatibility & Fit
CNC Connection CAT50
