Picture of Techniks 17140-1 BT40 Shell Mill 1.0000 25.40mm 3.5600 Gauge Length

Techniks 17140-1 BT40 Shell Mill 1.0000 25.40mm 3.5600 Gauge Length

Part Number: TEC17140-1 ISO: 17140-1

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TECHNIKS
SKU: 1419392
Vendor: Sussex Tool and Supply
$171.00
Techniks Techniks End Mill Holders Are Machined To H5 Standard I.D. Hole Tolerance. Balanced To 15,000 Rpm At G6.3 Tolerance To Save Spindle Bearing Life. Taper Is Ground To At3 Standard. Lab Certified With An Individualized Performance Report. Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Tool Material Steel
Machine Side Connection Type BT
Mach Side Connection Size 40
Overall Length 6.1300 155.70MM
Type Of Tool End Mill Holder
Insert/Tool TOOL
Part Side WELDON1.0000
Output Type Weldon
Output 1.0000 25.40MM
CNC Type Tool Shell Mill
CNC Conection BT40
CNC Out Put WELDON1.0000
Gauge Length 3.5600
Max RPM 15000
Nose Dia/Nut Dia 2.000
Balanced To 000 RPM at G6.3, 15
