Picture of Techniks 16313 BT30 Collet Chuck ER20 2.7600 Gauge Length

Techniks 16313 BT30 Collet Chuck ER20 2.7600 Gauge Length

Part Number: TEC16313 ISO: 16313
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1419344
Vendor: Sussex Tool and Supply
$124.96

Description

Techniks Techniks Collet Chucks Are Balanced To 25,000 Rpm At G2.5 Tolerance. Lab Tested For Accuracy And Balance And Come With Their Individual Performance Report. Techniks Holders Achieve 0.0001" Or Less T.I.R. From The Taper To The Collet Pocket. Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Coolant Thru Thru Coolant
Type Of Tool Collet Chuck
Output Type ER
CNC Type Tool Collet Chuck
Coolant Type Through Tool
Dimensions & Sizing
Overall Length 4.6600 118.36MM
Gauge Length 2.7600
Nose Dia/Nut Dia 1.100
Performance & Capacity
Output 20
Max RPM 25000
Balanced To 000 RPM at G2.5, 25
Materials & Finish
Tool Material Steel
Compatibility & Fit
CNC Connection BT30
