Picture of Techniks 16151F BT40 Collet Chuck ER16 2.7600 Gauge Length

Techniks 16151F BT40 Collet Chuck ER16 2.7600 Gauge Length

Part Number: TEC16151F ISO: 16151F

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TECHNIKS
SKU: 1419296
Vendor: Sussex Tool and Supply
$224.00
Techniks Coolflex Collet Chuck Offer Coolant Either Through The Spindle Or Flange (Din B). Remove Stop Screws For Din B. Balanced To 25,000 Rpm At G2.5 With T.I.R. Of 0.0001". Techniks Certified For Accuracy And Balance And Comes With A Lab Report. Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Tool Material Steel
Machine Side Connection Type BT
Mach Side Connection Size 40
Overall Length 5.3300 135.38MM
Coolant Thru Thru Coolant
Type Of Tool Collet Chuck
Insert/Tool TOOL
Part Side ER16
Output Type ER
Output 16
CNC Type Tool Collet Chuck
CNC Conection BT40
CNC Out Put ER16
Coolant Type Through Tool
Gauge Length 2.7600
Max RPM 25000
Nose Dia/Nut Dia 1.080
Balanced To 000 RPM at G2.5, 25
