Picture of Techniks 04545-9/16 Collet ER25 0.5625 14.29mm - 9/16 Metal Sealed

Techniks 04545-9/16 Collet ER25 0.5625 14.29mm - 9/16 Metal Sealed

Part Number: TEC04545-9/16 ISO: 04545-9/16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TECHNIKS
SKU: 1418819
Vendor: Sussex Tool and Supply
$65.00
Techniks Steel Sealed Collets Perfect For High Pressure Coolant Applications Because They Are Sealed To 2000 Psi With No PluGS To Fail. The Coolant-Thru Design Protects The Toolholder From Contaminants. Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Tool Material Steel
Machine Side Connection Type ER
Mach Side Connection Size 25
Overall Length 1.3390 34.01MM
Coolant Thru Thru Coolant
Tool Dia 1.0230 25.98MM
Type Of Tool Collet
Insert/Tool TOOL
Part Side Cylindrical0.5625
Output Type Cylindrical
Output 0.5625 14.29MM - 9/16
CNC Type Tool ER Coolant Collet
CNC Conection ER25
CNC Out Put CYLINDRICAL0.5625
Coolant Type Coolant Sealed
Collet Class AA "0.0004"
Collet/Chuck/Range 0.523 - 0.562 13.28MM - 14.27MM
Collet Seal Type Metal Seal
