Picture of Techniks 04544-5/16 Collet ER20 0.3125 7.94mm - 5/16 Metal Sealed

Techniks 04544-5/16 Collet ER20 0.3125 7.94mm - 5/16 Metal Sealed

Part Number: TEC04544-5/16 ISO: 04544-5/16
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1418785
Vendor: Sussex Tool and Supply
$45.63

Description

Techniks Steel Sealed Collets Perfect For High Pressure Coolant Applications Because They Are Sealed To 2000 Psi With No PluGS To Fail. The Coolant-Thru Design Protects The Toolholder From Contaminants. Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Coolant Thru Thru Coolant
Type Of Tool Collet
Output Type Cylindrical
CNC Type Tool ER Coolant Collet
Coolant Type Coolant Sealed
Collet Seal Type Metal Seal
Dimensions & Sizing
Overall Length 1.2240 31.09MM
Tool Dia 0.8270 21.01MM
Performance & Capacity
Output 0.3125 7.94MM - 5/16
Collet/Chuck/Range 0.273 - 0.312 6.93MM - 7.92MM
Tolerances & Accuracy
Collet Class AA "0.0004"
Materials & Finish
Tool Material Steel
Compatibility & Fit
CNC Connection ER20
