Picture of Sandvik A495-013M16-4509L, CoroMill 495 Chamfer Milling Cutter, 0.520" Cutting Diameter 45.0°, Chamfer Mill, Back Chamfer

Sandvik A495-013M16-4509L, CoroMill 495 Chamfer Milling Cutter, 0.520" Cutting Diameter 45.0°, Chamfer Mill, Back Chamfer

Part Number: SAN6536280 ISO: A495-013M16-4509L ANSI:A495-013M16-4509L

Need Assistance or Service? Please call 262-251-4020

Manufacturer: SANDVIK
SKU: 1014365
Vendor: Sussex Tool and Supply
$0.00
SANDVIK 6536280 Square 45.0°, Chamfer Mill, Back Chamfer End Mill Weldon 0.6250 Positive 0.5200 13.21MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Cutter Type Chamfer Mill, Back Chamfer
Tool Material Steel
Machine Side Connection Type Weldon
Mach Side Connection Size 0.6250 15.88MM
Overall Length 1.9290 49.00MM
Coolant Thru Thru Coolant
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Flutes/Inserts 1
Tool Dia 0.5200 13.21MM
Type Of Tool End Mill
Insert/Tool TOOL
Insert Application General Purpose
Insert Style 495
Insert Shape/Cutter Pocket Shape Square
Insert Type Positive
Insert Size Ic 9
Hand Right Hand
Coolant Type Internal
Depth Of Cut Max 0.1500
Cutting Edge Angle 45.0°
