Picture of RMC MDPNN-86-5DTurning Stick Tool 55.0° Insert Square 1.500 6.000 Oal Left Hand

RMC MDPNN-86-5DTurning Stick Tool 55.0° Insert Square 1.500 6.000 Oal Left Hand

Part Number: RMCMDPNN-86-5D ISO: MDPNN-86-5D ANSI:MDPNN-86-5D
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1054859
Vendor: Sussex Tool and Supply
$206.88

Description

RMC MDPNN-86-5D 55.0 ° Stick Tool1.5000 Negative Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA YES
Cutter Type Stick Tool
Type Of Tool Stick Tool
Insert/Tool TOOL
Cut Type General Purpose
Insert Style DN
Insert Shape/Cutter Pocket Shape 55.0°
Insert Type Negative
Hand Left Hand
Inter/Extern External
Clamp/Wedge CL-12
Seat/Nest IDSN-533
Seat Screw XNS-510
Lock Pin NL-58
Dimensions & Sizing
Overall Length 6.0000 152.40MM
Shank/Pilot Dia 1.5000 38.10MM - 1-1/2
Insert Size Ic 19 "54"
Tool Width 1.5000
Geometry & Angles
Lead Angle 62.5°
Lead Angle & Clearance Angle Combined 62.5° Lead Angle 60.0° Clearance Angle
Clearance Angle 60.0°
Materials & Finish
Tool Material Steel
Compatibility & Fit
Insert Fits 55.0°
