Picture of Nine 99616-3/4-120 Indexable Drill Weldon 0.7500 0.7500 19.05mm - 3/4Cutter Dia

Nine 99616-3/4-120 Indexable Drill Weldon 0.7500 0.7500 19.05mm - 3/4Cutter Dia

Part Number: EVE20374

Need Assistance or Service? Please call 262-251-4020

Manufacturer: NINE
SKU: 1004516
Vendor: Sussex Tool and Supply
$0.00

NINE drill with 3/4 cutter diameter 0.7500 inch 19.05mm Weldon toolpost connection steel tool material. Made in USA: No. Shipping state: ILLINOIS. Machine side connection: WELDON0.7500.

Key Details

Materials & Finish

  • Tool Material: Steel

Thread & Fittings

  • Machine Side (Toolpost) Connection Type: Weldon
  • Machine Side (Toolpost): WELDON0.7500

Grades & Coatings

  • Alternate Description: NINE 99616-3/4-120 Indexable Drill Weldon 0.7500 0.7500 19.05MM - 3/4Cutter Dia 99616-3/4-120 99616-3/4-120

Other Details

  • Brand: NINE
  • Shipping State: ILLINOIS
  • Made In Usa: No

Technical Overview

What It Does

Drills with 3/4 cutter diameter. Used in machine tool operations. Connects via Weldon system.

Composition

Steel tool material. Not specified.

Typical Uses

Drilling operations. Toolpost mounting. Machine side connection.

Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Cutter Type Cutter
Made In USA No
Tool Material Steel
Machine Side (Toolpost) WELDON0.7500
Machine Side (Toolpost) Connection Type Weldon
Overall Length 4.0000 101.60MM
Shank Or Pilot Diameter 0.7500 19.05MM - 3/4
Mach Side Connection Size 0.7500 19.05MM - 3/4
Tool Diameter 0.7500 19.05MM - 3/4
Insert Or Tool Tool
Insert Application General Purpose
Insert Style N9
Insert Size (IC) 11
Drill Type Indexable Drill
Depth Of Cut Max 0.1870
Type Indexable Drill Spot Drill
Cut Diameter Max 0.6690 16.99MM
