  • MELIN 11814 DIA 11/64 SH 0.1875 LOC 0.5156 OAL2.2500 End Mill Standard Flute Standard Helix Cobalt Uncoated Double End Square Sharp
Picture of MELIN 11814 DIA 11/64 SH 0.1875 LOC 0.5156 OAL2.2500 End Mill Standard Flute Standard Helix Cobalt Uncoated Double End Square Sharp

MELIN 11814 DIA 11/64 SH 0.1875 LOC 0.5156 OAL2.2500 End Mill Standard Flute Standard Helix Cobalt Uncoated Double End Square Sharp

Need Assistance or Service? Please call 262-251-4020

Manufacturer: MELIN
SKU: MEL11814
Delivery date: 3-5 days
$25.37
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cobalt steel is a type of high-speed alloy steel used primarily for cutting tools. Introduced to manufacturers in 1900, high-speed steel, containing a mixture of tungsten, chromium, and trace amounts of carbon, enabled manufacturers to double or even triple their production.

Products specifications
Attribute name Attribute value
General Product Information
Material # Material#15, Material#10, Material#8, Material#17, Material#3
Performance Rating General Performance
Sold by Pieces 1
Additional Key Information 2 Sharp
Additional Key Information 1 End Mill
Additional Key Information 3 Standard Flute
Application Slot Milling, Counterboring, Face Milling, Shoulder Milling
Shipping State Ohio/California
Additional Key Information 4 Standard Helix
Package Size 1
Uncategorized
Made In USA Yes
Dimensional Specifications
Machine Side WELDON0.1875
Inch/Metric Inch
Machine Side Connection Size 0.1875 4.76MM
Machine Side Connection Type Weldon
Length Of Cut 0.5157 13.10MM
Cutter Style Cobalt Finisher
Helix Angle 30°
Single/Double End Double End
Cutter Dia 0.1719 4.36MM - 11/64
Tool Material Cobalt
Overall Len 2.2500 57.15MM
Length Type Standard
Shank/Pilot Dia 0.1875 4.76MM - 3/16
Flutes/Inserts 4
Dimension Description 0.172 x 0.188 x 0.516 x 2.250
Cut Rating <40HRC Steel, Ductile Iron, Gray Iron, High Temp, Stainless Steel
End Of Tool Shape Square
Cutting & Machining Properties
Cutting Edge Mat Cobalt
Center Cutting Yes
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
