Picture of K-Tool SDCS-901 90° Spot Drills - 2 Flutes Effective - Must be held in a Collet Milling Cutter 1.000 Cutter Diameter 0.500 Round

K-Tool SDCS-901 90° Spot Drills - 2 Flutes Effective - Must be held in a Collet Milling Cutter 1.000 Cutter Diameter 0.500 Round

Part Number: KTOSDCS-901 ISO: SDCS-901 ANSI:SDCS-901
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1013105
Vendor: Sussex Tool and Supply
$175.09

Description

K-TOOL SDCS-901 Indexable Drill Spot Drill Cylindrical 0.5000 1.0000 25.40MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State PENNSYLVANIA
Made In USA YES
Cutter Type Cutter
Type Of Tool Spot Drill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style 901
Drill Type Indexable Drill
Type Indexable Drill Spot Drill
Clamp Screw 103212
Clamp/Wedge 501912
Dimensions & Sizing
Overall Length 3.0600 77.72MM
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Tool Dia 1.0000 25.40MM
Performance & Capacity
Cut Dia Min 0.1560 3.96MM
Cut Dia Max 0.6000 15.24MM
Materials & Finish
Tool Material Steel
