Picture of K-Tool SDCS-820 82° Spot Drills - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.625 Cutter Diameter 0.500 Round

K-Tool SDCS-820 82° Spot Drills - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.625 Cutter Diameter 0.500 Round

Part Number: KTOSDCS-820

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: 1013085
Vendor: Sussex Tool and Supply
$161.00
Products specifications
Attribute name Attribute value
Shank Or Pilot Diameter 0.5000 12.70MM - 1/2
Insert Application General Purpose
Cutter Type Cutter
Clamp Or Wedge 311205
Overall Length 3.2500 82.55MM
Insert Size (IC) 820
Machine Side (Toolpost) CYLINDRICAL0.5000
Clamp Screw 44025
Insert Style SD
Type of Tool Spot Drill
Insert Or Tool TOOL
Machine Side (Toolpost) Connection Type Cylindrical
Shipping State PENNSYLVANIA
Type Indexable Drill Spot Drill
Tool Material Steel
Mach Side Connection Size 0.5000 12.70MM - 1/2
Tool Diameter 0.6250 15.88MM - 5/8
Cut Diameter Min 0.0930 2.36MM
Cut Diameter Max 0.4000 10.16MM
Drill Type Indexable Drill
Made In USA YES
