Picture of K-Tool SDCS-100 100° Spot Drills - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.625 Cutter Diameter 0.500 Round

K-Tool SDCS-100 100° Spot Drills - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.625 Cutter Diameter 0.500 Round

Part Number: KTOSDCS-100 ISO: SDCS-100 ANSI:SDCS-100
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$152.76
SKU: 1013131

Description

K-TOOL SDCS-100 Indexable Drill Spot Drill Cylindrical 0.5000 0.6250 15.88MM - 5/8Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State PENNSYLVANIA
Made In USA YES
Cutter Type Cutter
Type Of Tool Spot Drill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style 100
Drill Type Indexable Drill
Type Indexable Drill Spot Drill
Clamp Screw 44025
Clamp/Wedge 311205
Dimensions & Sizing
Overall Length 3.2100 81.53MM
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Tool Dia 0.6250 15.88MM - 5/8
Performance & Capacity
Cut Dia Min 0.0930 2.36MM
Cut Dia Max 0.4700 11.94MM
Materials & Finish
Tool Material Steel
