Picture of K-Tool DT-1015 Milling Cutter 15.0° 1.000 Cutter Diameter 0.750 Weldon

K-Tool DT-1015 Milling Cutter 15.0° 1.000 Cutter Diameter 0.750 Weldon

Part Number: KTODT-1015 ISO: DT-1015 ANSI:DT-1015
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1013075
Vendor: Sussex Tool and Supply
$179.56

Description

K-TOOL DT-1015 55.0 ° 15.0°, Dove Tail End Mill Weldon 0.7500 Positive 1.0000 25.40MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State PENNSYLVANIA
Made In USA YES
Cutter Type Dove Tail
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Finishing, Semi Finishing
Insert Style DD
Insert Shape/Cutter Pocket Shape 55.0°
Insert Type Positive
Insert Screw 314T
Dimensions & Sizing
Overall Length 3.0000 76.20MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Flutes/Inserts 2
Tool Dia 1.0000 25.40MM
Insert Size Ic 21
Neck Length 1.0000 25.40MM
Neck Dia 0.83
Geometry & Angles
Cutting Edge Angle 15.0°
Performance & Capacity
Cut Dia Max 1.0000 25.40MM
Materials & Finish
Tool Material Steel
