Picture of K-Tool CBN-718 Milling Cutter 0.718 Cutter Diameter 0.750 Weldon

K-Tool CBN-718 Milling Cutter 0.718 Cutter Diameter 0.750 Weldon

Part Number: KTOCBN-718 ISO: CBN-718 ANSI:CBN-718

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: 1094723
Vendor: Sussex Tool and Supply
$263.00
K-TOOL CBN-718 Square 90.0°, Counterbore End Mill Weldon 0.7500 Positive 0.7180 18.24MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
Shipping State PENNSYLVANIA
Made In USA YES
Cutter Type Counter Bore
Tool Material Steel
Machine Side Connection Type Weldon
Mach Side Connection Size 0.7500 19.05MM
Overall Length 3.5000 88.90MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Flutes/Inserts 2
Tool Dia 0.7180 18.24MM
Type Of Tool End Mill
Insert/Tool TOOL
Insert Application General Purpose
Insert Style SP
Insert Shape/Cutter Pocket Shape Square
Insert Type Positive
Cut Dia Min 0.1880 4.78MM
Depth Of Cut Max 0.8750
Insert Screw 314T
Cutting Edge Angle 90.0°
