Picture of K-Tool CBN-2000 Milling Cutter 2.000 Cutter Diameter 1.250 Weldon

K-Tool CBN-2000 Milling Cutter 2.000 Cutter Diameter 1.250 Weldon

Part Number: KTOCBN-2000 ISO: CBN-2000 ANSI:CBN-2000
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1094736
Vendor: Sussex Tool and Supply
$441.31

Description

K-TOOL CBN-2000 Square 90.0°, Counterbore End Mill Weldon 1.2500 Positive 2.0000 50.80MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State PENNSYLVANIA
Made In USA YES
Cutter Type Counter Bore
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style SP
Insert Shape/Cutter Pocket Shape Square
Insert Type Positive
Insert Screw 1012T
Dimensions & Sizing
Overall Length 5.5000 139.70MM
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 2
Tool Dia 2.0000 50.80MM
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Cut Dia Min 0.5900 14.99MM
Depth Of Cut Max 2.5000
Materials & Finish
Tool Material Steel
