Picture of K-Tool CBN-15mm Milling Cutter 0.590 Cutter Diameter 0.750 Weldon

K-Tool CBN-15mm Milling Cutter 0.590 Cutter Diameter 0.750 Weldon

Part Number: KTOCBN-15MM ISO: CBN-15MM ANSI:CBN-15MM
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1094738
Vendor: Sussex Tool and Supply
$233.16

Description

K-TOOL CBN-15MM Square 90.0°, Counterbore End Mill Weldon 0.7500 Positive 0.5900 14.99MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State PENNSYLVANIA
Made In USA YES
Cutter Type Counter Bore
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style SP
Insert Shape/Cutter Pocket Shape Square
Insert Type Positive
Insert Screw 300T
Dimensions & Sizing
Overall Length 3.2500 82.55MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Flutes/Inserts 2
Tool Dia 0.5900 14.99MM
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Cut Dia Min 0.1500 3.81MM
Depth Of Cut Max 0.6250
Materials & Finish
Tool Material Steel
