Picture of Iscar T490 ELN D1.50-4-W1.25-13 Milling Cutter 90.0° 1.500 Diameter Weldon 1.250 4.500 OAL 4 Flute

Iscar T490 ELN D1.50-4-W1.25-13 Milling Cutter 90.0° 1.500 Diameter Weldon 1.250 4.500 OAL 4 Flute

Part Number: ISC3105303 ISO: T490 ELN D1.50-4-W1.25-13 ANSI:T490 ELN D1.50-4-W1.25-13

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: 1012283
Vendor: Sussex Tool and Supply
$555.00
ISCAR 3105303 90.0°, End Mill End Mill Weldon 1.2500 Negative 1.5000 38.10MM - 1-1/2Cutter Dia Steel
Products specifications
Attribute name Attribute value
Shipping State TEXAS
Made In USA NO
Cutter Type End Mill
Tool Material Steel
Machine Side Connection Type Weldon
Mach Side Connection Size 1.2500 31.75MM
Overall Length 4.5000 114.30MM
Coolant Thru Thru Coolant
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 4
Tool Dia 1.5000 38.10MM - 1-1/2
Type Of Tool End Mill
Insert/Tool TOOL
Insert Application Roughing, Semi Finishing
Insert Style LN
Insert Shape/Cutter Pocket Shape Other
Insert Type Negative
Insert Size Ic 13
Cut Dia Min 1.5000 38.10MM - 1-1/2
Coolant Type Through Hole
Depth Of Cut Max 0.4920
Cut Dia Max 1.5000 38.10MM - 1-1/2
Insert Screw 7000000
Cutting Edge Angle 90.0°
Max Ramp Angle 2.20°
