Picture of Iscar T290 ELN D1.0-3W1.0-10-XL Milling Cutter 90.0° 1.000 Diameter Weldon 1.000 5.000 OAL 3 Flute

Iscar T290 ELN D1.0-3W1.0-10-XL Milling Cutter 90.0° 1.000 Diameter Weldon 1.000 5.000 OAL 3 Flute

Part Number: ISC3105341 ISO: T290 ELN D1.0-3W1.0-10-XL ANSI:T290 ELN D1.0-3W1.0-10-XL
Tool Cross-Reference
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012297
Vendor: Sussex Tool and Supply
$477.12

Description

ISCAR 3105341 90.0°, End Mill End Mill Weldon 1.0000 Negative 1.0000 25.40MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type End Mill
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style LN
Insert Shape/Cutter Pocket Shape Other
Insert Type Negative
Coolant Type Through Hole
Insert Screw 7005132
Dimensions & Sizing
Overall Length 5.0000 127.00MM
Shank/Pilot Dia 1.0000 25.40MM
Flutes/Inserts 3
Tool Dia 1.0000 25.40MM
Insert Size Ic 10
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Cut Dia Min 1.0000 25.40MM
Depth Of Cut Max 0.3940
Cut Dia Max 1.0000 25.40MM
Materials & Finish
Tool Material Steel
