Picture of Iscar SOF45 D12.0-24-2.50-R18 Milling Cutter 45.0°, 44.0° 12.00 Diameter Face Mill 2.500 3.090 OAL 24 Flute

Iscar SOF45 D12.0-24-2.50-R18 Milling Cutter 45.0°, 44.0° 12.00 Diameter Face Mill 2.500 3.090 OAL 24 Flute

Part Number: ISC3107325 ISO: SOF45 D12.0-24-2.50-R18 ANSI:SOF45 D12.0-24-2.50-R18
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012655
Vendor: Sussex Tool and Supply
$4,665.60

Description

ISCAR 3107325 Multi 45.0°, 44.0° , Face Mill SHELL2.5000 Negative 12.0000 304.80MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Face Mill
Coolant Thru Non Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Finishing, Roughing, Semi Finishing
Insert Style SN, ON
Insert Shape/Cutter Pocket Shape Multi
Insert Type Negative
Coolant Type External
Insert Screw 7006977
Dimensions & Sizing
Overall Length 3.0900 78.49MM
Shank/Pilot Dia 2.5000 63.50MM
Flutes/Inserts 24
Tool Dia 12.0000 304.80MM
Insert Size Ic 07, 18
Geometry & Angles
Cutting Edge Angle 44.0°, 45.0°
Performance & Capacity
Cut Dia Min 12.0000 304.80MM
Depth Of Cut Max 0.0590
Cut Dia Max 12.6700 321.82MM
Materials & Finish
Tool Material Steel
