Picture of Iscar S845 F45SX D2.5-7-1.0-R16 Milling Cutter 45.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 7 Flute

Iscar S845 F45SX D2.5-7-1.0-R16 Milling Cutter 45.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 7 Flute

Part Number: ISC3105061 ISO: S845 F45SX D2.5-7-1.0-R16 ANSI:S845 F45SX D2.5-7-1.0-R16
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012221
Vendor: Sussex Tool and Supply
$836.16

Description

ISCAR 3105061 Square 45.0°, Face Mill SHELL1.0000 Negative 2.5000 63.50MM - 2-1/2Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Face Mill
Coolant Thru Thru Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Finishing, Roughing, Semi Finishing
Insert Style SX
Insert Shape/Cutter Pocket Shape Square
Insert Type Negative
Coolant Type Through Hole
Insert Screw 4305312
Dimensions & Sizing
Overall Length 1.7500 44.45MM
Flutes/Inserts 7
Tool Dia 2.5000 63.50MM - 2-1/2
Insert Size Ic 16
Geometry & Angles
Cutting Edge Angle 45.0°
Performance & Capacity
Cut Dia Min 2.5000 63.50MM - 2-1/2
Depth Of Cut Max 0.2760
Cut Dia Max 3.1270 79.43MM
Materials & Finish
Tool Material Steel
