Picture of Iscar S845 F45SX D2.0-4-.75-R16 Milling Cutter 45.0° 2.000 Diameter Face Mill 0.750 1.750 OAL 4 Flute

Iscar S845 F45SX D2.0-4-.75-R16 Milling Cutter 45.0° 2.000 Diameter Face Mill 0.750 1.750 OAL 4 Flute

Part Number: ISC3181207 ISO: S845 F45SX D2.0-4-.75-R16 ANSI:S845 F45SX D2.0-4-.75-R16
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012784
Vendor: Sussex Tool and Supply
Call (262) 251-4020 for pricing

Description

ISCAR 3181207 Square 45.0°, Face Mill SHELL0.7500 Negative 2.0000 50.80MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Face Mill
Coolant Thru Thru Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Finishing, Roughing, Semi Finishing
Insert Style SX
Insert Shape/Cutter Pocket Shape Square
Insert Type Negative
Coolant Type Through Hole
Insert Screw 7006316
Dimensions & Sizing
Overall Length 1.7500 44.45MM
Flutes/Inserts 4
Tool Dia 2.0000 50.80MM
Insert Size Ic 16
Geometry & Angles
Cutting Edge Angle 45.0°
Performance & Capacity
Cut Dia Min 2.0000 50.80MM
Depth Of Cut Max 0.2760
Cut Dia Max 2.5800 65.53MM
Materials & Finish
Tool Material Steel
