Picture of Iscar PH D2.00-H040-W1.25-13 Milling Cutter 2.000 Diameter Weldon 1.250 4.430 OAL 4 Flute

Iscar PH D2.00-H040-W1.25-13 Milling Cutter 2.000 Diameter Weldon 1.250 4.430 OAL 4 Flute

Part Number: ISC3181177 ISO: PH D2.00-H040-W1.25-13 ANSI:PH D2.00-H040-W1.25-13
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$711.36
SKU: 1012780

Description

ISCAR 3181177 Rectagonal Plunge Mill End Mill Weldon 1.2500 Negative 2.0000 50.80MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Plunge Mill
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style PL
Insert Shape/Cutter Pocket Shape Rectagonal
Insert Type Negative
Coolant Type Through Hole
Insert Screw 7003603
Dimensions & Sizing
Overall Length 4.4300 112.52MM
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 4
Tool Dia 2.0000 50.80MM
Insert Size Ic 13
Performance & Capacity
Cut Dia Min 2.0000 50.80MM
Depth Of Cut Max 0.3030
Materials & Finish
Tool Material Steel
